𐄀 Technology Connection to Future
Applicable to V2L application in European Union area.
High protection
High structural strength
Minimalist assembly
Lightweight design
| Specifications | ||
ltem | 16A serie | |
Type of power | Single-phase | |
Standard | IEC62196-1:2022 IEC62196-2:2022 | |
Rated voltage | 220V AC | |
Rated current | 16A AC | |
Voltage resistance | 2000V AC | |
| Insulation resistance | ≥500MΩ | |
Degree of protection | Connector | Before insertion: IP54; After insertion: IP55 Electrical part: : IP67(Except the interface with socket) |
Strip | IPXXB | |
| Cycles life | Connector | ≥10000 |
| Strip | ≥5000 | |
Insertion and withdrawal force | <100N | |
Ambient temperature | -30℃ ~+ 50℃ | |
Flame retardant rating | UL94 V-0 | |
Coating material of power contacts | Ag | |
| External cable diameter | Φ8.5±0.2mm | |
Tailoring connectors to your unique needs.
Provide system-level solutions
Respond to needs within 12 hours
