𐄀 Technology Connection to Future
Applicable to the corresponding standard DC charging station in European Union area.
High protection
High structural strength
Accurate temperature monitoring
Lightweight design
Ergonomic design
Aesthetic design of family style
| Specifications | |||||
ltem | 80A series | 125A series | 200A series | 250A series | 300A series |
Standard | IEC62196-1:2022 IEC62196-3:2022 IEC61851-1:2017 | ||||
Rated voltage | 1000V DC | ||||
Rated current | 80A DC | 125A DC | 200A DC | 250A DC | 300A DC |
Voltage resistance | 3000V AC | ||||
Insulation resistance | 2500MΩ | ||||
Degree of protection | Before insertion(with cap): IP55; Afterinsertion: IP54 Electrical part: : IP67(Except the interface with socket) | ||||
Cycles life | ≥10000 | ||||
Insertion and withdrawal force | <100N | ||||
Ambient temperature | -30°C ~ +50℃ | ||||
Flame retardant rating | UL94 V-0 | ||||
Coating material of power contacts | Ag | ||||
| External cable diameter | Φ25±0.5mm | Φ26.5±0.5mm | Φ24.5±0.5mm | Φ32±0.5mm | Φ34±0.5mm |
Tailoring connectors to your unique needs.
Provide system-level solutions
Respond to needs within 12 hours
