Applicable to the corresponding standard electric vehicles in China area for DC charging. lt needs to be connected to the liquid cooling system of the vehicle.
High protection
Self-developed cooling components
High rated current-carrying capacity
Accurate temperature monitoring
Corrosion-resistant flange
Wear silver technology import
| Specifications | |
ltem | 900A series |
Standard | GB/T 20234.1-2023 GB/T 20234.3-2023 GB/T 18487.1-2023 GB/T 18487.5-2024 |
Rated voltage | 1000V DC |
Rated current | 900A DC |
Voltage resistance | 3000V AC |
Insulation resistance | ≥500MΩ |
Degree of protection | Before insertion: IP54; After insertion: IP55 Electrical part: : IP67(Except the interface with connector) |
Cycles life | ≥10000 |
lnsertion and withdrawal force | <140N |
Ambient temperature | -40℃ ~ +125℃ |
Flame retardant rating | UL94 V-0 |
Coating material of power contacts | Ag |
Cooling circuit | One inlet pipe and one outlet pipe |
Cooling medium | Ethylene Glycol-Based coolant predilute(GB 29743) |
Minimum flow velocity | 1L/min |
| Maximum working pressure | 2.5Bar |
Tailoring connectors to your unique needs.
Provide system-level solutions
Respond to needs within 12 hours
