Applicable to the corresponding standard DC charging station in European Union area. lt needs to be connected to the suitable liquid cooling system.
High protection
High structural strength
Accurate temperature monitoring
Lightweight design
Ergonomic design
Aesthetic design of family style
| Specifications | |||
ltem | 500A series | 600A series | |
Standard | IEC62196-1:2022 IEC62196-3:2022 IEC62196-3-1:2022 IEC61851-1:2017 | ||
Rated voltage | 1000V DC | ||
Rated current | 500A | 600A | 800A |
Peak current | 600A | 800A | |
Voltage resistance | 3000V AC | ||
Insulation resistance | >500MΩ | ||
Degree of protection | Before insertion(with cap): IP55﹔After insertion: IP54 Electrical part: : IP67(Except the interface with socket) | ||
Cycles life | ≥10000 | ||
Insertion and withdrawal force | <100N | ||
Ambient temperature | -30℃ ~+ 50℃ | ||
Flame retardant rating | UL94 V-0 | ||
Coating material of power contacts | Ag | ||
External cable diameter | Φ31±0.5mm | Φ32±0.5mm | |
Minimum bending radius | 10D | ||
Cooling circuit | Two inlet pipes and two outlet pipes | ||
| Cooling medium | TF8016/TF8025 | ||
