Mainly used in railroads, rolling stock, urban rail transportation, electronic communications, mining terminals and industrial equipment automation electrical control system between the electrical signal connection.
Contact specification | Φ1.6 | Φ2.4 | Φ3.6 | Φ5.75 | Φ8 |
Rated current | 13A | 23A | 46A | 80A | 150A |
Contact resistance | ≤2.5mΩ | ≤1.3mΩ | ≤0.8mΩ | ≤0.5mΩ | 0.35mΩ |
Insulation resistance | ≥5000MΩ | 5000MΩ | 5000MΩ | 5000MΩ | 5000MΩ |
Mechanical life | 750 times | ||||
Vibration | According to GB/T21563-2008 requirements in accordance with the provisions of category 2 | ||||
Shock | According to GB/T21563-2008 requirements in accordance with the provisions of category 2 | ||||
Operating temperature | -55℃～+125℃ | ||||
Humidity | 95%（40℃） | ||||
Protection class | IP67（with suitable tail accessories） | ||||
Environmentally Friendly | RoHS | ||||
Material and surface treatment | Housing: Aluminum alloy; Surface treatment: Oxidized black | ||||
Tailoring connectors to your unique needs.
Provide system-level solutions
Respond to needs within 12 hours
